THLB_PRODUCT CENTER

Electric vehicles lithium battery

POWER

Powered supplied with advantages of high performance lithium battery:
● strong ability to run, high energy rate, light and small size, long cycle life, and high safety, high voltage platform and good resistance;
● It can ensure the products work continuous, high effective, and stable, and safe and clean;
● flexible and small size, can be customized design ;
● Mostly used for mobile power supply, lamp, toy, UPS, wearable equipments, portable Bluetooth loudspeaker, starting up batteries, outdoor lamp, portable tools,etc

Dowload

Lithium battery is the power source of EV, and the only guarantee for the stable operation of EV, with high capacity, free

maintenance and long working time, it is widely used now for e-bike, e-motocycle, wheel chair, forklift, electrical cars, AGV,

detecting vehicles, etc.

Model	Charge current	charge voltage	Discharge current	Discharge voltage
12.8V600Ah	20A	14.4V	20A	10V
14.4V18Ah	5A	16.8V	25A	12.0V
25.6V48Ah	9.6A	28.8V	60A	20V
25.6V60Ah	12A	28.8V	60A	20V
25.6V75Ah	15A	28.8V	60A	20V
25.6V100Ah	20A	28.8V	100A	20V
25.6V180Ah	36A	28.8V	140A	20V
36V6.6Ah	4A	42V	15A	30V
36V72Ah	14.4A	42V	60A	30V
38.4V28.8Ah	6A	43.2V	30A	30V
38.4V100Ah	20A	43.2V	60A	30V
46.8V24.2Ah	4.84A	54.6V	50A	39V
46.8V90Ah	18A	54.6V	100A	39V
46.8V63Ah	12.5A	54.6V	60A	39V
46.8V112.5Ah	22.5A	54.6V	60A	39V
50.4V90Ah	18A	58.8V	50A	42V
50.4V108Ah	21.6A	58.8V	50A	42V
51.2V25Ah	5A	57.6V	25A	40V
51.2V44Ah	8.8A	57.6V	44A	40V
51.2V60Ah	12A	57.6V	50A	40V
51.2V90Ah	18A	57.6V	50A	40V
51.2V30Ah	6A	57.6V	60A	40V
51.2V35Ah	7A	57.6V	60A	40V
51.2V150Ah	30A	57.6V	100A	40V
51.2V200Ah	40A	57.6V	120A	40V
72V90Ah	18A	84V	120A	60V
76.8V192Ah	38.4A	86.4V	120A	60V
179.2V10Ah	2A	201.6V	30A	140V
97.2V231Ah	30A	113.4V	200A	81.0V
